Features:
Column base design, high-end atmosphere
All aluminum material design, novel appearance
Waterproof treatment of patented structure
Low thermal resistance path cooling design
Professional optical design, high efficiency and uniform light output
Design of high efficiency, high PF value and low heating power supply
Outdoor lightning protection design
Color: RGB full color, RGBW, regular white, warm white, amber yellow
Optical source high power 1W / 3W
The light output angle is 8 degrees, 15 degrees, 30 degrees, 45 degrees, 60 degrees
Working temperature - 20 ℃ ~ 50 ℃
Storage temperature - 40 ℃ - 70 ℃
Working voltage: DC24 V, AC24 V, AC220 V
Control mode: DMX512
Protection grade: IP67
Service life: 50000 hours
| Specification type | Shell | Light source | Power | Working voltage | Driving current | Color temperature |
| JML-M200DC-24M | Die cast aluminum | 24X1W | 24W | AC220V | 340mA | monochrome |
| JML-M200DC-30M | Die cast aluminum | 30X1W | 30W | AC220V | 340mA | monochrome |
| JML-M200DC-36M | Die cast aluminum | 36X1W | 36W | AC220V | 340mA | monochrome |
| JML-M200DC-48M | Die cast aluminum | 24X2W | 48W | AC220V | 680mA | monochrome |
| JML-M200DC-60M | Die cast aluminum | 30X2W | 60W | AC220V | 680mA | monochrome |
| JML-M200DC-72M | Die cast aluminum | 36X2W | 72W | AC220V | 680mA | monochrome |
| JML-M200DC-24R | Die cast aluminum | 24X1W | 24W | DC24V | 3X340mA | RGB |
| JML-M200DC-30R | Die cast aluminum | 30X1W | 30W | DC24V | 3X340mA | RGB |
| JML-M200DC-36R | Die cast aluminum | 36X1W | 36W | DC24V | 3X340mA | RGB |
| JML-M200DC-48R | Die cast aluminum | 24X2W | 48W | DC24V | 3X680mA | RGB |
| JML-M200DC-60R | Die cast aluminum | 30X2W | 60W | DC24V | 3X680mA | RGB |
| JML-M200DC-72R | Die cast aluminum | 36X2W | 72W | DC24V | 3X680mA | RGB |
