Features:
All aluminum material design, novel appearance
Patented structure waterproof treatment
Large area heat dissipation design
Ultra small angle light effect design
Heat dissipation design of low thermal resistance path
Professional optical design, efficient and uniform light output
Design of high efficiency, high PF value and low heating power supply
Outdoor lightning protection design
Color RGB full color, RGBW, positive white, warm white, succinic yellow
Optical source high power 1W / 3W
Light output angle: 3 °, 8 °, 15 °, 30 °, 45 °, 60 °, more angles are optional
Working temperature - 20 ℃ ~ 50 ℃
Storage temperature - 40 ℃ ~ 70 ℃
Working voltage: DC24V, AC24V, AC220V
Control mode DMX512
Protection grade: IP67
Service life: 50000 hours
| Conventional angle | ||||||
| Specification type | Shell | Light source | Power | Working voltage | Driving current | Color temperature |
| JML-T401L-150M | Die cast aluminum | 50X3W | 150W | AC220V | 1000mA | monochrome |
| JML-T401L-180M | Die cast aluminum | 60X3W | 180W | AC220V | 1000mA | monochrome |
| JML-T401L-200M | Die cast aluminum | 72X2.8W | 200W | AC220V | 980mA | monochrome |
| JML-T401L-150R | Die cast aluminum | 50X3W | 150W | DC24V | 1000mA | monochrome |
| JML-T401L-180R | Die cast aluminum | 60X3W | 180W | DC24V | 1000mA | monochrome |
| JML-T401L-200R | Die cast aluminum | 72X2.8W | 200W | DC24V | 980mA | monochrome |
| Conventional angle(3°) | ||||||
| Specification type | Shell | Light source | Power | Working voltage | Driving current | Color temperature |
| JML-T401L-120M | Die cast aluminum | 24X5W | 120W | AC220V | 1650mA | monochrome |
| JML-T401L-140M | Die cast aluminum | 28X5W | 140W | AC220V | 1650mA | monochrome |
| JML-T401L-160M | Die cast aluminum | 32X5W | 160W | AC220V | 1650mA | monochrome |
