Features:
All aluminum material design, novel appearance
Deep anti glare design
Professional anti dazzle grille function
Patented structure waterproof treatment
Heat dissipation design of low thermal resistance path Professional optical design, efficient and uniform light output Design of high efficiency, high PF value and low heating power supply
Outdoor lightning protection design
Color RGB full color, RGBW, positive white, warm white, succinic yellow
Optical source high power 1W / 3W
Light output angle: 3 °, 8 °, 15 °, 30 °, 45 °, 60 °, more angles are optional
Working temperature - 20 ℃ ~ 50 ℃
Storage temperature - 40 ℃ ~ 70 ℃
Working voltage: DC24V, AC24V, AC220V
Control mode DMX512
Protection grade: IP67
Service life: 50000 hours
| Conventional angle | ||||||
| Specification type | Shell | Light source | Power | Working voltage | Driving current | Color temperature |
| JML-T200BC-24M | Die cast aluminum | 24X1W | 24W | AC220V | 340mA | monochrome |
| JML-T200BC-30M | Die cast aluminum | 30X1W | 30W | AC220V | 340mA | monochrome |
| JML-T200BC-36M | Die cast aluminum | 36X1W | 36W | AC220V | 340mA | monochrome |
| JML-T200BC-48M | Die cast aluminum | 24X2W | 48W | AC220V | 680mA | monochrome |
| JML-T200BC-60M | Die cast aluminum | 30X2W | 60W | AC220V | 680mA | monochrome |
| JML-T200BC-72M | Die cast aluminum | 36X2W | 72W | AC220V | 680mA | monochrome |
| JML-T200BC-24R | Die cast aluminum | 24X1W | 24W | DC24V | 3X340mA | RGB |
| JML-T200BC-30R | Die cast aluminum | 30X1W | 30W | DC24V | 3X340mA | RGB |
| JML-T200BC-36R | Die cast aluminum | 36X1W | 36W | DC24V | 3X340mA | RGB |
| JML-T200BC-48R | Die cast aluminum | 24X2W | 48W | DC24V | 3X680mA | RGB |
| JML-T200BC-60R | Die cast aluminum | 30X2W | 60W | DC24V | 3X680mA | RGB |
| JML-T200BC-72R | Die cast aluminum | 36X2W | 72W | DC24V | 3X680mA | RGB |
| Ultra small angle（3°） | ||||||
| Specification type | Shell | Light source | Power | Working voltage | Driving current | Color temperature |
| JML-T200BC-27M | Die cast aluminum | 9X3W | 27W | AC220V | 1020mA | monochrome |
| JML-T200BC-36M | Die cast aluminum | 12X3W | 36W | AC220V | 1020mA | monochrome |
| JML-T200BC-45M | Die cast aluminum | 9X5W | 45W | AC220V | 1650mA | monochrome |
| JML-T200BC-60M | Die cast aluminum | 12X5W | 60W | AC220V | 1650mA | monochrome |
