Features:
All aluminum material design, novel appearance Deep anti glare design Professional anti dazzle grille function Patented structure waterproof treatment Heat dissipation design of low thermal resistance path Professional optical design, efficient and uniform light output Design of high efficiency, high PF value and low heating power supply Outdoor lightning protection design
Color RGB full color, RGBW, positive white, warm white, amber
Light source high power 1W / 3W
The light output angle is 3 °, 8 °, 15 °, 30 °, 45 °, 60 °, and more angles are optional
Working temperature - 20 ℃ ~ 50 ℃
Storage temperature - 40 ℃ ~ 70 ℃
Working voltage: DC24V, AC24V, AC220V
Control mode DMX512
Protection class IP67
Service life 50000 hours
| Conventional angle | ||||||
| Specification type | Shell | Light source | Power | Working voltage | Driving current | Color temperature |
| JML-T160BC-12M | Die cast aluminum | 12X1W | 12W | AC220V | 340mA | monochrome |
| JML-T160BC-15M | Die cast aluminum | 15X1W | 15W | AC220V | 340mA | monochrome |
| JML-T160BC-18M | Die cast aluminum | 18X1W | 18W | AC220V | 340mA | monochrome |
| JML-T160BC-24M | Die cast aluminum | 12X2W | 24W | AC220V | 680mA | monochrome |
| JML-T160BC-30M | Die cast aluminum | 15X2W | 30W | AC220V | 680mA | monochrome |
| JML-T160BC-36M | Die cast aluminum | 18X2W | 36W | AC220V | 680mA | monochrome |
| JML-T160BC-12R | Die cast aluminum | 12X1W | 12W | DC24V | 3X340mA | RGB |
| JML-T160BC-15R | Die cast aluminum | 15X1W | 15W | DC24V | 3X340mA | RGB |
| JML-T160BC-18R | Die cast aluminum | 18X1W | 18W | DC24V | 3X340mA | RGB |
| JML-T160BC-24R | Die cast aluminum | 12X2W | 24W | DC24V | 3X680mA | RGB |
| JML-T160BC-30R | Die cast aluminum | 15X2W | 30W | DC24V | 3X680mA | RGB |
| JML-T160BC-36R | Die cast aluminum | 18X2W | 36W | DC24V | 3X680mA | RGB |
| Ultra small angle（3°） | ||||||
| Specification type | Shell | Light source | Power | Working voltage | Driving current | Color temperature |
| JML-T160BC-18M | Die cast aluminum | 6X3W | 18W | AC220V | 1020mA | monochrome |
| JML-T160BC-30M | Die cast aluminum | 6X5W | 30W | AC220V | 1650mA | monochrome |
